library(survival)
library(dplyr)
library(speff2trial)
library(devtools)
library(survRM2)
library(purrr)
# library(smim)
load_all()

Data Cleanning

The dataset is avaiable in speff2trial::ACTG175.

# Load dataset
data(ACTG175)

Pattern
- 1: observed event time
- 2: MAR imputation
- 3: MNAR imputation
Delta
- 1: no adjustment
- larger than 1: hazard is larger than MAR
- less than 1: hazard is smaller than MAR

# Analysis data: antiretroviral naive and no history of intravenous drug use
db <- ACTG175 %>% subset(drugs == 0 & strat == 1)
db <- db %>% mutate(time = days / 30.25,
              age = (age - mean(age)) / sd(age),
              status = cens,
              group = arms,
              pattern = ifelse(status == 1, 1, ifelse(time >= 24, 2, 3))) %>%
         subset(group %in% c(0, 1)) %>%
         mutate(group = ifelse(group == 0, 0, 1) )

fit <- survfit(Surv(time, status) ~ group, data = db )
plot(fit, col = c(1,2))

time <- db$time
status <- db$status
group <- db$group
pattern <- db$pattern
x <- db %>% select(age, symptom)
tau <- 2 * 12

Summary statistics

nrow(db)
#> [1] 382

table(group)
#> group
#>   0   1
#> 197 185

table(status)
#> status
#>   0   1
#> 296  86

n_mi <- 50
n_b <- 100
seed <- 1234

Delta Adjusted Imputation

RMST within group

.delta <- seq(1, 5, by = 0.5)
res <- map(.delta, function(delta0){
  delta   <- ifelse(group == 0, c(1,1,1)[pattern], c(1,1,delta0)[pattern])  # the third number control delta adjustment for MNAR
  tmp <- rmst_delta(time, status, x = x, group, pattern, delta, tau, n_mi = n_mi, n_b = n_b, seed = seed)
  tmp
})
res0 <- map(res, function(x) as.data.frame(x$rmst))
names(res0) <- .delta
res0 <- bind_rows(res0, .id = "delta")

res0 %>% mutate(
  lower = rmst - 1.96 * sd,
  upper = rmst + 1.96 * sd,
  lower_wb = rmst - 1.96 * wb_sd,
  upper_wb = rmst + 1.96 * wb_sd
) %>% mutate_if(is.numeric, formatC, digits = 2, format = "f")
#>    delta group  rmst   sd wb_sd lower upper lower_wb upper_wb
#> 1      1  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 2      1  1.00 23.04 0.24  0.22 22.56 23.52    22.60    23.48
#> 3    1.5  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 4    1.5  1.00 23.02 0.25  0.22 22.54 23.50    22.58    23.46
#> 5      2  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 6      2  1.00 23.00 0.25  0.23 22.51 23.49    22.56    23.44
#> 7    2.5  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 8    2.5  1.00 22.98 0.25  0.23 22.49 23.47    22.54    23.43
#> 9      3  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 10     3  1.00 22.97 0.25  0.23 22.47 23.46    22.52    23.41
#> 11   3.5  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 12   3.5  1.00 22.95 0.25  0.23 22.45 23.45    22.51    23.40
#> 13     4  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 14     4  1.00 22.93 0.26  0.23 22.43 23.44    22.49    23.38
#> 15   4.5  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 16   4.5  1.00 22.92 0.26  0.23 22.42 23.42    22.47    23.37
#> 17     5  0.00 22.12 0.31  0.32 21.52 22.73    21.50    22.75
#> 18     5  1.00 22.90 0.26  0.23 22.40 23.41    22.45    23.35

RMST between group

diff_rmst <- function(data){
  rmst <- data$rmst
  sd <- data$sd
  diff <- diff(rmst)
  diff_sd <- sqrt( sum(sd^2) )
  p_val <- 2* (1 - pnorm( abs(diff/diff_sd) ))
  print(c(diff = diff, sd = diff_sd, p = p_val))
  return(1)
}

res0 %>% group_by(delta) %>% summarise(
  diff_rmst = diff(rmst),
  diff_sd = sqrt( sum(sd^2) ),
  diff_wb_sd = sqrt(sum(wb_sd^2)),
  lower = diff_rmst - 1.96 * diff_sd,
  upper = diff_rmst + 1.96 * diff_sd,
  p_val = 2* (1 - pnorm( abs(diff_rmst/diff_sd) )),
  lower_wb = diff_rmst - 1.96 * diff_wb_sd,
  upper_wb = diff_rmst + 1.96 * diff_wb_sd,
  p_val_wb = 2* (1 - pnorm( abs(diff_rmst/diff_wb_sd) )),
) %>% mutate_if(is.numeric, formatC, digits = 3, format = "f") %>% data.frame()
#>   delta diff_rmst diff_sd diff_wb_sd  lower upper p_val lower_wb upper_wb
#> 1     1     0.915   0.394      0.389  0.143 1.686 0.020    0.151    1.678
#> 2   1.5     0.896   0.395      0.390  0.122 1.671 0.023    0.133    1.660
#> 3     2     0.877   0.397      0.390  0.100 1.655 0.027    0.113    1.642
#> 4   2.5     0.859   0.398      0.390  0.078 1.639 0.031    0.094    1.624
#> 5     3     0.843   0.399      0.391  0.062 1.625 0.034    0.078    1.609
#> 6   3.5     0.826   0.400      0.391  0.042 1.610 0.039    0.060    1.592
#> 7     4     0.810   0.401      0.391  0.024 1.596 0.043    0.043    1.577
#> 8   4.5     0.794   0.402      0.392  0.006 1.582 0.048    0.026    1.562
#> 9     5     0.778   0.403      0.392 -0.012 1.568 0.054    0.009    1.547
#>   p_val_wb
#> 1    0.019
#> 2    0.021
#> 3    0.024
#> 4    0.028
#> 5    0.031
#> 6    0.035
#> 7    0.038
#> 8    0.043
#> 9    0.047

Control Based Imputation

delta   <- c(1,1,1)[pattern]  # the third number control delta adjustment for MNAR
tmp <- rmst_control(time, status, x = x,
                    group = group,
                    ref_grp = 0, pattern = pattern, delta = delta, tau = tau,
                    n_mi = n_mi, n_b = n_b, seed = seed)
tmp$rmst
#>      group     rmst        sd     wb_sd
#> [1,]     0 22.12450 0.3091611 0.3183603
#> [2,]     1 23.00746 0.2478957 0.2247016

RMST between group

first row: Rubin’s rule
second row: Wild bootstrap

diff_rmst <- function(rmst, sd){
  diff <- diff(rmst)
  diff_sd <- sqrt( sum(sd^2) )
  p_val <- 2* (1 - pnorm( abs(diff/diff_sd) ))
  c(diff = diff, sd = diff_sd, p = p_val)
}

x <- rbind( diff_rmst(tmp$rmst[,"rmst"], tmp$rmst[, "sd"]),
       diff_rmst(tmp$rmst[,"rmst"], tmp$rmst[, "wb_sd"]))
x <- as.data.frame(x)
x$lower <- x$diff - 1.96 * x$sd
x$upper <- x$diff + 1.96 * x$sd
round(x, digits = 3)
#>    diff    sd     p lower upper
#> 1 0.883 0.396 0.026 0.106 1.660
#> 2 0.883 0.390 0.023 0.119 1.647

Direct Estimator (Tian et.al 2014)

rmst2(time, status, group, tau= tau)
#>
#> The truncation time: tau = 24  was specified.
#>
#> Restricted Mean Survival Time (RMST) by arm
#>                Est.    se lower .95 upper .95
#> RMST (arm=1) 23.050 0.242    22.576    23.524
#> RMST (arm=0) 22.117 0.311    21.508    22.725
#>
#>
#> Restricted Mean Time Lost (RMTL) by arm
#>               Est.    se lower .95 upper .95
#> RMTL (arm=1) 0.950 0.242     0.476     1.424
#> RMTL (arm=0) 1.883 0.311     1.275     2.492
#>
#>
#> Between-group contrast
#>                       Est. lower .95 upper .95     p
#> RMST (arm=1)-(arm=0) 0.934     0.162     1.705 0.018
#> RMST (arm=1)/(arm=0) 1.042     1.007     1.079 0.018
#> RMTL (arm=1)/(arm=0) 0.504     0.278     0.914 0.024

Model Diagnosis

Placebo group

fit0 <- coxph(Surv(time, status) ~ age + symptom, data = subset(db, group == 0))
cox.zph(fit0)
#>           chisq df    p
#> age     1.26036  1 0.26
#> symptom 0.00477  1 0.94
#> GLOBAL  1.27130  2 0.53

fit_cen0 <- coxph(Surv(time, 1 - status) ~ age + symptom, data = subset(db, group == 0))
cox.zph(fit_cen0)
#>         chisq df     p
#> age      3.31  1 0.069
#> symptom  1.49  1 0.222
#> GLOBAL   4.60  2 0.100

Treatment group

fit1 <- coxph(Surv(time, status) ~ age + symptom, data = subset(db, group == 1))
cox.zph(fit1)
#>         chisq df    p
#> age     0.133  1 0.71
#> symptom 0.420  1 0.52
#> GLOBAL  0.480  2 0.79

fit_cen1 <- coxph(Surv(time, 1 - status) ~ age + symptom, data = subset(db, group == 1))
cox.zph(fit_cen1)
#>         chisq df     p
#> age     3.002  1 0.083
#> symptom 0.105  1 0.746
#> GLOBAL  3.004  2 0.223
